Electrode Backing

MPL Carbon Cloth (Single sided)

SKU: GDLSS.
Brands: .
Price: $15.00 – $325.00
Clear
Quantity:
- +
  • Description
  • Technical Details
  • Reviews (0)

Product Description

MPL Carbon Cloth is a Single sided micro porous layer gas diffusion layer. MPL Carbon Cloth has been engineered to have state-of-the-art performance over a wide range of operating conditions. The thickness of this GDL carbon cloth is about 385 um.

Gas Diffusion Layers (GDL) are key components of the membrane electrode assembly of the polymer electrolyte membrane fuel cell (PEMFC).

Suggested Uses

  • Fuel cells
  • Electrolysis
  • Flow through Batteries
  • Water Clean-up Electrochemistry

Additional information

Weight lbs
Dimensions 0.000 × 0.000 × 0.000 in
Basic Weight

200/160 g/M2
Porosity (%)

50 microns
Gas Permeability

0.01565 x 10-¹³ m²-secGas permeability Darcy’s Law
Electrical Conductivity (Bulk)

7 mohm cm (through plane)
Density

0.51 g/cc
Thickness

385 microns (0.5 psi)
Size

5cm x 5cm, 10cm x 10cm, 20cm x 20cm, 40cm x 40cm
Material Type

Woven Carbon Fiber
Carbon Content (%)

99.5 in woven, variable in coating for hydrophobicity
